Thermal analysis of wavy finned heat sinks through cross-cut modifications under natural convection
DOI:
https://doi.org/10.15282/jmes.20.2.2026.1.0869Keywords:
cfd, heat sink, wavy fin, Natural ConvectionAbstract
Wavy fin heat sinks offer significant potential for thermal management due to their enhanced surface area compared to conventional straight-fin designs. However, the effect of surface area on thermal resistance is not straightforward since thermal resistance depends on the inverse product of surface area and the convective heat transfer coefficient. This study investigates the relationship between surface area, convective heat transfer coefficient, and thermal resistance for wavy fin heat sinks under natural convection. Experimental tests were conducted on a l parallel-fin heat sink (HS1) and a wavy-fin heat sink (HS2) using a polyimide heater supplying 4 W of input power. Thermal resistance is determined from steady-state temperature measurements using three thermocouples located at the heat sink base. Despite having an approximately 10% greater surface area, HS2 exhibited a thermal resistance of 14.85 K/W, about 4.7% higher than HS1 (14.19 K/W). This highlights that increased area alone does not guarantee improved performance. This is attributed to a lower convective heat transfer coefficient (8.38 vs. 9.71 Wm⁻²K⁻¹) caused by restricted airflow within the wavy fin channels. Three-dimensional steady state computational fluid dynamics simulations on four cross-cut variants of HS2 are performed to investigate the effect of geometric modifications on the convective heat transfer performance. The HS2B showed a reducing thermal resistance by up to 3% (5.57 K/W) while slightly decreasing surface area compared to HS2(16.21 K/W). These results demonstrate that effective heat sink design under natural convection requires the balancing surface area and convective heat transfer coefficient.
References
[1] A. R. Dhumal, A. P. Kulkarni, and N. H. Ambhore, “A comprehensive review on thermal management of electronic devices,” Journal of Engineering and Applied Science, vol. 70, no. 1, p. 140, 2023, https://doi.org/10.1186/s44147-023-00309-2.
[2] Z. Zhang, X. Wang, and Y. Yan, “A review of the state-of-the-art in electronic cooling,” e-Prime - Advances in Electrical Engineering, Electronics and Energy, vol. 1, p. 100009, 2021, https://doi.org/10.1016/j.prime.2021.100009.
[3] W. Elenbaas, “Heat dissipation of parallel plates by free convection,” Physica, vol. 9, no. 1, pp. 1–28, 1942, https://doi.org/10.1016/S0031-8914(42)90053-3.
[4] C. D. Jones and L. F. Smith, “Optimum arrangement of rectangular fins on horizontal surfaces for free-convection heat transfer,” ASME Journal of Heat Transfer, vol. 92, no. 1, pp. 6–10, 1970, https://doi.org/10.1115/1.3449648.
[5] M. H. Cobble, “Nonlinear fin heat transfer,” Journal of the Franklin Institute, vol. 277, no. 3, pp. 206–216, 1964, https://doi.org/10.1016/0016-0032(64)90478-8.
[6] A. Brown, “Optimum dimensions of uniform annular fins,” International Journal of Heat and Mass Transfer, vol. 8, no. 4, pp. 655–662, 1965, https://doi.org/10.1016/0017-9310(65)90051-7.
[7] A. L. London and R. K. Shah, “Offset Rectangular Plate-Fin Surfaces—Heat Transfer and Flow Friction Characteristics,” Journal of Engineering for Power, vol. 90, no. 3, pp. 218–228, 1968, https://doi.org/10.1115/1.3609175.
[8] Y. K. Prajapati, “Influence of fin height on heat transfer and fluid flow characteristics of rectangular microchannel heat sink,” International Journal of Heat and Mass Transfer, vol. 137, pp. 1041–1052, 2019, https://doi.org/10.1016/J.IJHEATMASSTRANSFER.2019.04.012.
[9] M. Winter and J. A. Weibel, “The Effect of Fin Array Height and Spacing on Heat Transfer Performance during Pool Boiling from Extended Surfaces,” in 2022 21st IEEE Intersociety Conference on Thermal and Thermomechanical Phenomena in Electronic Systems (iTherm), 2022, pp. 1–7. https://doi.org/10.1109/iTherm54085.2022.9899575.
[10] H. Fuse, S. Oe, and T. Haga, “Effects of fin height, base thickness, blackening, emissivity and thermal conductivity on heat dissipation of die-cast aluminum alloy heat sink,” Metals (Basel), vol. 15, no. 7, 2025, https://doi.org/10.3390/met15070696.
[11] M. Ismail, “Experimental and numerical analysis of heat sink using various patterns of cylindrical pin-fins,” International Journal of Thermofluids, vol. 23, p. 100737, 2024, https://doi.org/10.1016/j.ijft.2024.100737.
[12] H. Ehsani, F. N. Roudbari, S. S. Namaghi, p. Jalili, and D. D. Ganji, “Investigating thermal performance enhancement in perforated pin fin arrays for cooling electronic systems through integrated CFD and deep learning analysis,” Results in Engineering, vol. 22, p. 102016, 2024, https://doi.org/10.1016/j.rineng.2024.102016.
[13] A. Hewage Dona Kalpani Rasangika, M. Shakir Nasif, and R. Al-Waked, “Numerical investigation on the thermal performance of perforated and non-perforated twisted fins at different twisting angles,” Results in Engineering, vol. 23, p. 102332, 2024, https://doi.org/10.1016/j.rineng.2024.102332.
[14] M. Harris, H. Wu, A. Angelopoulou, W. Zhang, Z. Hu, and Y. Xie, “Heat transfer optimisation using novel biomorphic pin-fin heat sinks: An integrated approach via design for manufacturing, numerical simulation, and machine learning,” Thermal Science and Engineering Progress, vol. 51, p. 102606, 2024, https://doi.org/10.1016/j.tsep.2024.102606.
[15] G. W. Kim, H. M. Lim, and G. H. Rhee, “Numerical studies of heat transfer enhancement by cross-cut flow control in wavy fin heat exchangers,” International Journal of Heat and Mass Transfer, vol. 96, pp. 110–117, May 2016, https://doi.org/10.1016/j.ijheatmasstransfer.2016.01.023.
[16] K. Nilpueng, H. S. Ahn, D. W. Jerng, and S. Wongwises, “Heat transfer and flow characteristics of sinusoidal wavy plate fin heat sink with and without crosscut flow control,” International Journal of Heat and Mass Transfer, vol. 137, pp. 565–572, 2019, https://doi.org/10.1016/J.IJHEATMASSTRANSFER.2019.03.114.
[17] P. Sun, M. A. Ismail, and A. F. Mustaffa, “Metamodel-based design optimization for heat transfer enhancement of finned heat sinks,” International Journal of Thermal Sciences, vol. 214, p. 109896, 2025, https://doi.org/10.1016/j.ijthermalsci.2025.109896.
[18] R. J. Moffat, “Describing the uncertainties in experimental results,” Experimental Thermal and Fluid Science, vol. 1, no. 1, pp. 3–17, 1988, https://doi.org/10.1016/0894-1777(88)90043-X.
[19] Y. A. Cengel and A. J. Ghajar, Heat and mass transfer: Fundamentals and applications. McGraw-Hill Professional, 2014.
[20] “ANSYS Fluent User’s Guide, Release 2024 R1.”
[21] I. A. Fetuga et al., “Computational fluid dynamics of free convection and radiation on thermal performance of light emitting diode applications with trapezoidal-finned heat sink,” Case Studies in Thermal Engineering, vol. 61, p. 105078, Sep. 2024, https://doi.org/10.1016/J.CSITE.2024.105078.
[22] C. H. Huang and W. Y. Chen, “A natural convection horizontal straight-fin heat sink design problem to enhance heat dissipation performance,” International Journal of Thermal Sciences, vol. 176, p. 107540, Jun. 2022, https://doi.org/10.1016/J.IJTHERMALSCI.2022.107540.
